FRIWO | UK

*PSU Shown with EU plug fitted
FOX12 MEDICAL USB
FW-Type: FW8000M/USB
Medical Grade Interchangeable USB Power Supply

Input Voltage:   100 - 240V AC (±10%)


Output voltage:   Various (see table below)


Frequency:   50 - 60Hz


Leakage Current:   ≤ 10µA


Stand-by:   ≤ 0.1W


MTBF:   200,000 hours acc. Mil217F (based on calculations at 120Vac/60Hz & 230Vac/50Hz, ambient 25°C and 100% load)

(The MTBF are theoretically determined values, which does not guarantee the lifetime of the product or of the electrolytic capacitors)

Operating Temperature:   0 - 40°C


Storage Temperature:   -40 - 70°C


Operating Altitude:   3000m


Humidity:   10 - 95%


Standards:   IEC 60601-1


Approvals:   EU, USA, AUS, JPN


Safety Class:   II


EMC:   EN 55022, EN 55024


Overload & Overvoltage protection


Continuously short circuit proof


DOE Level VI Efficiency

PSU Dimensions:   78 x 31.5 x 41mm


Weight:   80g


Housing Flame Class:   UL 94 V0


Casing:   Double Safety, Snapped & Welded


Plug Connector:   AC input / Interchangeable primary adapter system


DC output:   Secondary adapter system


View Accessories

IP Rotection rating:   IP40


Condcted and Radiated Emmisions:   N55032, EN55011, FCC15, Class B, EN60601-1-2


Immunity:  EN55024, EN60601-1-2


Harmonics:   EN61000-3-2


Flicker noise:  EN61000-3-3


ESD (contact/ air):  EN61000-4-2


Immunity against radiated field:  EN61000-4-3


ETF/ Burst:  EN61000-4-4


Surge: EN61000-4-5


Immunity against conducted disturbances: EN61000-4-6


Voltage dips:  EN61000-4-11


Immunity against magnetic field: EN61000-4-8


Drop test: Standard: IEC 60068-2-32, Surface: steel, Drop height: 1 m, Numbers of Drops (total): 3


Vibration:  Standard: IEC 60068-2-6, Frequency range : 10 – 500 Hz, Cross- over-frequency : 58 – 62 Hz, Displacement amplitude : 0.2mm, Peak acceleration : 3 g, Number of cycles: 10 per axis

AVAILABLE OUTPUTS
CLICK TILES BELOW TO DOWNLOAD RELEVANT DATASHEET
A blue 5v logo on a white background.
A blue 5v logo on a white background.
A blue letter v with three dots on a white background.

CUSTOM OUTPUT

Available for OEM Projects

that meet the required MOQ

Button
Required Accessories

For the operation of this device you need a primary AC adapter
This can be found here: ACCESSORIES

IPX2 FOX PLUGS

NEW!

The optional IP42 plug adapter from FRIWO is an interchangeable adapter system that offers additional protection for use in damp environments.
This PSU is also available as...
INDUSTRIAL GRADE
FIXED DC CONNECTOR
FIXED PLUG
