FRIWO | UK
MPP30
FW-Type: FW7304
30 Watt Industrial Grade NiCd/NimH Charger
NiCd/NimH
BATTERY CHARGER
*PSU Shown with EU plug fitted
Dimensions
Technical Data
| Input voltage | 100 – 240 V ± 10 % |
|---|---|
| Frequency | 50 – 60 Hz |
| Input current | 400 – 500 mA |
| Leakage current | ≤ 100 μA |
| Output voltage tolerance | ± 10 % |
| Efficiency | DoE: Energy Efficiency level VI |
| MTBF | 100.000 h* |
* Mil217F based on calculations at 120 VAC / 60 Hz & 230 VAC / 50 Hz,
Ambient temperature 25°C, 100% load
Available Outputs
To access the respective datasheet, just click on the appropriate download button below.
Environmental specifications
| Operating temperature | 0 – 40° C |
|---|---|
| Humidity | 5 – 95 % |
| Storage temperature | -40 – 70° C |
| Operating altitude | 2000 m |
Safety specifications
| Safety Standard | IEC 60335-2-29, UL 2601 |
|---|---|
| Approvals | UK, EU, US, AUS |
| Safety Class | II |
| EMC | EN 55011, EN 55022/B, FCC 47 part 15, EN 61000 |
REQUIRED ACCESSORIES
AC Input Plugs
To ensure the seamless functioning of this device, you will require a AC adapter that is compatible with the specific country's power requirements.
