Dimensions

Technical Data
Input voltage | 100 – 240 V ± 10 % |
---|---|
Frequency | 50 – 60 Hz |
Input current | 2000 – 700 mA |
Leakage current | ≤ 10 μA |
Output voltage tolerance | ± 5 % |
Stand-by | ≤ 0.5 W |
MTBF | 200.000 h* |
* Mil217F based on calculations at 120 VAC / 60 Hz & 230 VAC / 50 Hz,
Ambient temperature 25°C, 100% load
Available Outputs
To access the respective datasheet, just click on the appropriate download button below.
Environmental specifications
Operating temperature | 0 – 40° C |
---|---|
Humidity | 5 – 95 % |
Storage temperature | -40 – 70° C |
Operating altitude | 4000 m |
Safety specifications
Safety Standard | IEC 60601-1 |
---|---|
Approvals | UK, EU, USA |
Safety Class | II |
EMC | EN 60601-1-2:2015 |
Medical Protection | 2 x MOPP |
REQUIRED ACCESSORIES
AC Power Cords
You will require a AC cable that is compatible with the IEC320 C8 socket.
DC Output Leads
Check out our range of 'Snap-In' DC connectors that fit onto this unit.
