FRIWO | UK

DT50-M

FW-Type: FW7405M

50 Watt Medical Grade Desktop Power Supply

A black and white cross icon on a white background.

Medical Grade

A black and white icon of a desktop power supplyon a white background.

Desktop Model

A black desktop power supply is sitting on a white surface.
Tick

Efficiency Level VI

Tick

Overload Protection

Tick

Overvoltage Protection

Tick

Short Circuit Proof

Dimensions

A black and white drawing of a desktop power supply with measurements on a white background.

Technical Data

Input voltage 100 – 240 V ± 10 %
Frequency 50 – 60 Hz
Input current 1100 – 500 mA
Leakage current ≤ 10 μA
Output voltage tolerance ± 5 %
Turn-on delay ≤ 3 s
Stand-by ≤ 0.75 W
MTBF 200.000 h*

* Mil217F based on calculations at 120 VAC / 60 Hz & 230 VAC / 50 Hz,

Ambient temperature 25°C, 100% load

Available Outputs

To access the respective datasheet, just click on the appropriate download button below.

5V 5000mA

FW7405M/DT/05

Part Number: 1890649

12V 3800mA

FW7405M/DT/12

Part Number: 1890650

15V 3000mA

FW7405M/DT/15

Part Number: 1890839

24V 2200mA

FW7405M/DT/24

Part Number: 1825898

...V ...mA

Need a Custom Solution?

Just get in touch and see how we can help you!

Environmental specifications

Operating temperature 0 – 40° C
Humidity 10 – 90 %
Storage temperature -40 – 70° C
Operating altitude 4000 m

Safety specifications

Safety Standard IEC 60601-1
Approvals UK, EU, USA, AUS
Safety Class II
EMC EN 60601-1-2 4th Edition
Medical Protection 2 x MOPP

Labels / Certifications

A black and white logo for uk ca on a white background.
A black and white ce logo on a white background.
A black and white logo for a company called siq on a white background.
A black and white triangle with a check mark inside of it.
The RU logo is a black and white logo on a white background.

Further approvals possible after consultation.


Want to know more about Safety Agencies & Markings?

VIEW BLOG

REQUIRED ACCESSORIES

Friwo 50W Desktop Power Supply

AC Power Cords

You will require a AC cable that is compatible with the IEC320 C8 socket.


AC Power Cords

DC Output Leads

Check out our range of 'Snap-In' DC connectors that fit onto this unit.


'Snap-In' DC Connectors
